DZ SERIES DOUBLE BOX

  1. Home
  2. Roller blinds
  3. GUIDED ROLLER BLINDS
  4. DZ SERIES DOUBLE BOX

APPLICATION: Horizontal, Inclined
Installation: indoor

The DZ Resstende Series presents the motorized horizontal roller blind for interiors only, effective for skylights and medium-large sized inclined windows, with double box, suitable for guaranteeing total darkening where required

CHARACTERISTICS:

Application: ZIP system that combines the horizontal double box motorised blind with the Zip guide for a smooth running indoor blind and guaranteed containment of the fabric inside the channels. Ideal for medium/large slanted windows and sklights.
Installation: indoor
Headbox: two C105/CT105/C104 extruded aluminum headboxes with removable covers and aluminium end cheeks
Roller tube: Ø 78 mm extruded galvanized steel tube
Side channels: GS40 extruded aluminum side channels in two parts with winged inner rail in PVC. The ZIP system ensures smooth operation keeping the fabric inside the channels and provides total blackout where required
Hem bar: FZ47 extruded aluminum weighted fl at hem bar with PVC end caps and brush
Color: white Ral 9010, matt black Ral 9005, silver anodised
Operation: motorised operation; 230V/50Hz tubolar motor M50, with top/bottom limit switches and mains cable, thermal cut-out and class IP44 water resistance. Costant torque springs CONSTON hidden in the opposite headbox to keep the fabric taut in any position
Mounting: the blind is supplied with the side channels ready mounted on a 40x25x3 mm aluminium frame to facilitate installation
Dimensioni: Min. L 80 x H 100 cm – Max L 250 x H 300 cm

Click here for information or download our complete catalogue here
